Heavy Duty Wide Beam Total Invisible Long Range Night Vision IR Illuminator

Lighten up areas where camera cannot view in total darkness
Weatherproof Metal Housing for All Harsh Environments

Home security, Business night surveillance, Home alone Pet watch, School Security, Police Raid
Pool Surveillance, Large Warehouse Surveillance, Infants safety, Property security, Animal Watch
Ground Troop Raid, Wild Animal video, Zoo keeping, Bird net watch, Garden watch, Natural Life observation
Backyard Watch, Outdoor security, Hidden surveillance, Spy video, Live video, Video surveillance, Nanny Cam

Invisible IR LED shows no Red Glow on the tip of LED, Completely Stealthed to
Human Eyes for Best Night Surveillance & Perfect for Undetected Wildlife Video Observation!




click to enlarge...click to enlarge...click to enlarge...

click to enlarge...                   click to enlarge...



" Revised "

Item#

ENC-907A

ENC-907B

ENC-907C

ENC-907D

Description

90ft Range IR Illuminator

150ft Range IR Illuminator

300ft Range IR Illuminator

1100ft Range IR Illuminator

Inventory Status

Out of Stock

In Stock

In Stock

Out of Stock


click to enlarge...

click to enlarge...

click to enlarge...

click to enlarge...

IR LED

140pcs of Φ5mm
Small Size LED

48pcs of Φ10mm
Super Large LED

96pcsof Φ10mm
Super Large LED

60pcs x2
Dot-Matrix LED

Beam Angle

70º

50º

50º

75º

Wave Length

950NM(Invisible)

950NM(Invsible)

950NM(Invsible)

950NM(Invsible)

Beam distance

up to 90ft

up to 150ft

up to 300ft

up to 1,100ft

Click the photos to view real video clips

click to play real video clip...



click to play real video clip...



Viewed w/ ECC-200T



Viewed w/ ECC-200T



Power Input & Consumption

DC12V / 400mA

DC12V / 500mA

DC12V / 1300mA

AC110~220V / 31W

Weight

1LBS 11oz

1LBS 15oz

2LBS

17.2LBS

Dimension

W6.75"xH5"xD4.25"

W5"xH3.5"xD3.5"

L6.9"xH5"xD4.25"

L16.3"xH10.8"xD5.8"

Housing

IP65 All Weather Metal Housing

IP65 All Weather Metal Housing

IP65 All Weather Metal Housing

IP66 All Weather Metal Housing in Angle Adjustable 2x Panels

Cooling Fan

Yes

No (Not necessary)

Yes

Yes

Red Glow on LED

No & Totally Invisible

No & Totally Invisible

No & Totally Invisible

No & Totally Invisible

Operating Temp

-20ºC ~ 50ºC
(-4ºF ~ 122ºF)

-20ºC ~ 50ºC
(-4ºF ~ 122ºF)

-20ºC ~ 50ºC
(-4ºF ~ 122ºF)

-40ºC ~ 55ºC
(-40ºF ~ 131ºF)

Washout White Glow Effect

Wide angle beam Minimizes Wash-out Effect even when objects are in the close range.

Special Functions

Built-in +12V regulator circuits for over 2-year life span of LEDs

Built-in CdS Sensor to Turn On-Off IR LEDs at about 10.0 LUX

Required Camera Specification

Your camera must feature or capable to turn it on manually if available any one of the required specification among Daynight function, AGC (Auto Gain Control), ALG (Auto Level Control), Auto Change of Color Video to B&W at Night, or Absorptive type IR-cut filters must be removed automatically or manually at night in order to view the IR light properly. Additionally it is strongly recommended the LUX level of your camera offers at least 0.01 LUX or lower in order to view the IR light up to the maximum distance as it offered; otherwise the IR light won’t be viewed correctly.

Auto Iris Lens

Should be set to ALC (Auto Level Control) for the correct IR vision

Special Note

Hardware specification is subject to change without prior notice

Illuminator Set Includes

Built-in Mounting Bracket Set, AC/DC Power Supply, & Quick Starter Guide
