iPhone,  Android, & Windows Mobile 6.1 Compatible Fast Network 16CH Standalone DVR

FAST INTERNET REMOTE VIEW
View remote video on your iPhone (App base : Blazing fast)
Real-time Live & Recording DVR System
MPEG4 CODEC / Pentaplex / 480 FPS Live & Recording
16 Channel Video / 1 Ch Audio / 4 Ch Alarm In/Out

Great application for Realtime Remote Video Surveillance & PTZ Camera Control



click to enlarge...                     click to enlarge...



Sale Price $200 off >

US$990.00

Regular Price >

US$1,190.00



Item#

ESD-PE1648

Description

Pro Remote Viewable Fast Network 16CH Standalone DVR w/ Built-in 1TB HDD & DVR-RW

Features


KEY FEATURES:
* User Friendly GUI (Flexible, Easy and Convenient)
* Advanced CMS Software (Convenient and Versatile Software)
* S.M.A.R.T (Self Monitoring Analysis and Reporting Technology)
* Dual Stream (Dual Streaming for High Speed Internet)
* External Storage (Maximum External Storage Extension)

CMS FEATURES:
* Up to X 64 Channel Display
* Remote Multi Site Control
* Remote PTZ Control
* Health Check System
* Remote Setup (Configuration)
* Remote Event Search Engine
* Remote Date/Time Search Engine
* 2-Way Audio (Bi-Directional)
* Local Recording (NVR Function) & Playback
* Local Playback
* Archiving (EXE/JPEG File Format)
* Remote Alarm Out Control - Local Audio Out Volume Control - Local Account
* Remote Log Display
* Remote Camera Color Adjustment
* WCS (Watermark Check System)
* E-MAP
* Keyboard Controller
* Remote S/W Upgrade

Web Client FEATURES:
* Multi Channel Display
* PTZ Control
* Live Monitoring
* Freeze Function
* Channel and Camera Number Display


Compression

Advanced MPEG4 ASP / Pentaplex

Operating System

Embedded Linux

OS Firmware

Linux OS in Flash Memory

NTSC / PAL Selectable

Yes

Video Input

Composite 16 BNC Inputs

Video Output

Composite: 1 (1Vp-p, 75 Ohm)

Monitor Output

1 VGA

Sequence

Yes

Max Recording Rate at CIF (FPS)

480 (NTSC) / 400 (PAL)

Max Recording Rate at H.D1 (FPS)

240 (NTSC) / 200 (PAL)

Max Recording Rate at Full D1 (FPS)

120 (NTSC) / 100 (PAL)

Audio Input

1 Input (RCA)

Audio Output

1 Output (RCA)

Ethernet

10 / 100Mbps Ethernet (RJ-45)

Network Bandwidth Control

26 kbps ~ Unlimited

Video Stream

Dual

Alarm Input

4 (TTL) Programmable as NC/NO

Alarm Output

4 (TTL) Programmable as NC/NO

USB Interface

4 x USB2.0 (2 x Front Panel, 2 x Rear Panel)

Search (Date/Time, Calendar, Event)

Yes

User Interface (GUI / Control Device)

Yes / Keypad, Mouse, PTZ Control, Remote Controller

External Storage

None

Archive File Format

EXE (Video Clip) / JPEG (Still Image)

NTP Server

Yes

GMT Time Zone

Yes

Auto DST

Yes

Recording Qualities

Super / High / Standard

Recording Modes

Continuous / Alarm / Motion / Emergency

Pre-Alarm Recording

Up to 3 Hours / User Programmable

Motion Detection

Yes (22 x 15)

Playback Control

x1, x2, x4, x8, x16, x32, x64, Extreme

PTZ Control

RS-485/422 Serial Port 1

Preset Touring

Yes

POS / ATM Support

Up to 4 Channels Over USB (Optional)

Multi Language

English / Danish / Chinese (Traditional) / Japanese / Korean / Italian / Polish / Russian / Chinese (Simplified) / Thai / Turkish / Spanish / French / Czech / German / Persian / Portuguese / Croatian

Primary Storage

SATA HDD (Up to 2+1)

Clip Copy Storage

Built-in Internal DVD-RW, Memory Stick

Dimension (WxHxD)

350 mm x 65 mm x 380 mm / 13.78 inch x 2.56 inch x 14.96 inch

Operating Temperature

5C~40C / 41F~104F

Operating Humidity

0% ~ 90%

Power Adapter

Free Voltage 12VDC, 5A

Power Consumption

Max 40W

Agency Approval

FCC / CE
