Item#
|
ESD-PE0824
|
Description
|
iPhone
Viewable Fast Network 8CH Standalone DVR w/ Built-in 1TB HDD
|
Features
|
Convenience:
* User-friendly
GUI (Graphic User Interface)
* Easy-to-use
menu composition
* Easy-to-use
recorded data search (Time, Date, Motion, Alarm)
* Easy-to-use
menu with USB Mouse.
Stability:
* Auto
restart after power interruption
* DB
structure offers data stabilization and best storage utilization
* Expandability:
* Various
remote multi DVR's can be controlled by Web browser (PC Client
System)
Technology:
* Embedded
LINUX OS
* Totally
maximum recording rate 120 fps
* High-resolution
& High-quality H.264 algorithm
* Using
Water marking & scrambling technologies
* Strong
protection recorded data
* H.264
: 1 ~ 2 Kbytes per image with resolution 360 x 240
Functionality:
* Variable
recording function (normal, alarm, motion, schedule, audio, Time
Lapse)
* Full
channel real-time monitoring
* Live
monitoring, recording, playback, backup, remote access at the same
time
* Multi
channel playback
* Variable
events notification to e-mail, buzzer or PC Client system
|
Video
|
Camera
Input (NTSC, PAL)
|
8
CH DVR
|
Output
|
1
BNC, 1 VGA, 1 SPOT
|
Audio
|
Audio
Input
|
1
RCA
|
Output
|
1
RCA
|
Sensor
in (No, Nc) / Alarm Out
|
1
/ 1
|
Compatible
Mobile Device
|
iPhone
& Android
|
Operating
System
|
Embedded
Linux OS
|
Display
|
Speed
|
240
fps
|
Resolution
(Pixel)
|
720*480
(NTSC) / 720*576 (PAL)
|
Split
Screen
|
1,
4, 8
|
Recording
|
Compression
|
H.
264
|
Resolution
(Pixel)
|
720*480,
720*240, 360*240 (NTSC) / 720*576, 720*288, 360*288 (PAL)
|
Quality
|
3
Steps (High, Middle, Low)
|
Mode
|
Normal,
Motion, Alarm
|
Priority
|
Alarm
-> Motion -> Normal
|
Speed
(Total)
|
NTSC:
30fps(720x480), 60fps(720x240) 120fps(360x240)
|
PAL:
25fps(720x480), 50fps(720x240) 100fps(360x240)
|
Speed
(Each Chanel)
|
NTSC:
1fps(720x480), 3fps(720x240) 7fps(360x240)
|
PAL:
1fps(720x480), 3fps(720x240) 6fps(360x240)
|
Water
Marking & Scrambling
|
Our
Own Algorithm
|
Playback
|
Display
|
1,
4, 8
|
Search
Mode
|
Date
& Time, Calendar, Event (Alarm, Motion, Audio)
|
Speed
|
Normal,
REW (*1,2,4,16) & FF (*1,*2,*4,*16), Frame to frame, Pause
|
Device
|
Internal
HDD
|
Still
Image Capture & Save
|
JPEG,
BMP Compression or Exclusive Format & USB I/F Device (Memory
Stick)
|
Network
|
Network
Interface
|
Ethernet
|
Protocol
|
TCP/IP,
SMTP, HTTP, DHCP, PPPOE (ADSL)
|
Serial
Communication
|
RS-232
1each, RS-485 1ea (PTZ & Keyboard control)
|
Application
|
Windows
2000 / XP (PC Client System) / Windows Vista / Windows 7
|
Web
Browser
|
Internet
Explorer 5.0 Higher (DVRs Control or Viewing)
|
Event
Transport
|
E-mail
notification when Event Occurs
|
Viewing
|
Remote
Client, Internet Explorer, CMS
|
Archive
|
Interface
|
USB
2.0x 1ea
|
Archive
Device
|
External
HDD, CD & DVDRW, Network, Memory Stick
|
Control
|
Motion
Detection
|
Each
Control / Channel
|
Sensitivity
: 3 Steps for each channel
|
Area
: Programmable motion detection area for each camera individually
|
Alarm
Hold Time
|
5
~ 240 SEC
|
Event
Log
|
Up
to the 256 events (Alarm, Motion, Video & Power Loss, Power &
Record On/Off)
|
Controller
|
IR
Remote Control / Mouse
|
Pan
/ Tilt Camera
|
Control
From RS485 Interface
|
Others
|
HDD
|
Built-in
1,000GB
|
Power
Source
|
100
~ 240V AC, 50 ~ 60Hz
|
Power
Consumption
|
36W
|
Operating
Temperature
|
5
~ 40°C (41 ~ 104F)
|
Relative
Humidity
|
Maximum
80% Non-Considering
|
Weight
|
Net
: 3.0Kg
|
Gross
(Box) : 5.0Kg
|
Dimension
|
Net
: 355(W) * 245(D) * 60(H)mm
|
Gross
(Box) : 400(W) * 340(D) * 142(H)mm
|
|
